Max Payload 30000 kg Double Deck Animal Poultry Livestock Semi Trailer with 3/4 Axles

Max Payload 30000 kg Double Deck Animal Poultry Livestock Semi Trailer with 3/4 Axles
Max Payload 30000 kg Double Deck Animal Poultry Livestock Semi Trailer with 3/4 Axles Max Payload 30000 kg Double Deck Animal Poultry Livestock Semi Trailer with 3/4 Axles Max Payload 30000 kg Double Deck Animal Poultry Livestock Semi Trailer with 3/4 Axles Max Payload 30000 kg Double Deck Animal Poultry Livestock Semi Trailer with 3/4 Axles Max Payload 30000 kg Double Deck Animal Poultry Livestock Semi Trailer with 3/4 Axles Max Payload 30000 kg Double Deck Animal Poultry Livestock Semi Trailer with 3/4 Axles

Large Image :  Max Payload 30000 kg Double Deck Animal Poultry Livestock Semi Trailer with 3/4 Axles

Product Details:
Place of Origin: Shandong, China
Brand Name: Yun Cheng
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: $9,800.00/sets >=1 sets
Payment Terms: T/T, L/C
Contact Now

Max Payload 30000 kg Double Deck Animal Poultry Livestock Semi Trailer with 3/4 Axles

Description
Use: Truck Trailer Type: Semi-Trailer
Material: Steel Size: 12400x2500x3650mm
Max Payload: >30000 Kg Color: Customization
Axle: 3/4 Axles King Pin: 2"(50#) Or 3/5"(90#)
Main Bean: Q345B Rim: 9.00-22.5
Tire: 12.00R 22.5 Suspension: Air Or Mechanical
Brake System: Air Champer Leadtime: 15 Days
Condition: New

Products Description
Max Payload 30000 kg Double Deck Animal Poultry Livestock Semi Trailer with 3/4 Axles 0
Fence Semi trailer
Fence semi trailer used for transporting various kinds of good , such as daily necessities, building  material , agricultural products and so on , here is special for livestock
It is usually composed of two parts of the body chassis and the upper warehouse  grid, the body chassis is used for carrying and suspension , and the upper warehouse grid is used to fixed and protect the goods , but also can play a role in preventing the goods from slipping
Max Payload 30000 kg Double Deck Animal Poultry Livestock Semi Trailer with 3/4 Axles 1
Max Payload 30000 kg Double Deck Animal Poultry Livestock Semi Trailer with 3/4 Axles 2
Max Payload 30000 kg Double Deck Animal Poultry Livestock Semi Trailer with 3/4 Axles 3
Max Payload 30000 kg Double Deck Animal Poultry Livestock Semi Trailer with 3/4 Axles 4
Drawing
Max Payload 30000 kg Double Deck Animal Poultry Livestock Semi Trailer with 3/4 Axles 5
Specification
Detail Specification
Items
fence semi trailer
Tare Weight
7.5 Tons (depends on final configuration)
Payload
50 tons or cutomizable
Size
12400x2500x3650mm (customizable)
Inside size
12200x2300x600mm (customization)
Main Beam
Q345B/T700 steel
Height 500mm
Upper Plate is 14mm
Down plate is 16mm
Middle plate is 8mm or customization
Side Beam
16mm channel steel ( material is q235b steel)
Bottom Plate
Thickness 3mm ( customization)
Sidewall Thickness
1.5-2.5MM Q235 steel (customization)
Sidewall Height
600mm (customization)
Lifting System
130 Hydraulic lifting cylinder
Axles
13/16/20 tons, axle amount optional like 2/3/4 axles etc, axle brand optional like SAF, FUWA, BPW etc
King pin
2.00"(50#), bolting king pin, JOST  or another brand according to customer
Suspension
Mechanical suspension air suspension (American or Geman)
Leaf Spring
Six sets of reliable famous brand , 10pcs leaf spring, thickness 13mm. width 90mm
Landing gear
28tons lifting capacity , Brand optinal FUWA/JOST etc can be choose
Tire specs
12R22.5/315 80R22.5/11R20/12R20 Choose freely
 Braking system
dual line brake system , Air chamber T30/30 3X40L gas storage drums
Rim
9.00-22.5 /8.00-20/8.5-20
ABS system
None or installed as your requirement.
Painting
Sanding , anti-corrosion , one primer paining add two layer top coat painting
Side Gurd
According to customer
Electrical system
24 volt electrical system 7 pin electrical connector, Parking stop, reverse, number plate and indicator lights, rear lights conform to european  standard, rear front and side reflectors
spare tire
Two set of heavy duty spare wheel carriers, indluding a riser
Tool Box
One Piece (1.0 x 5.0 m) with 1 tire spanner, 1 gudgeon sleeve and 1 cranking bar
Color
According to customers requirements
Delivery
From China Port and carry by container ship, ro-ro ship or by bulk
Remark
Our senior engineer can design semi trailer as your request, and we accept OEM/ODM projects
Max Payload 30000 kg Double Deck Animal Poultry Livestock Semi Trailer with 3/4 Axles 6

Suspention - Anti-Tire Abrasion

Specially designed anti-Tire abrasion suspension system prevent tire deflection after loading and avoids tires to the maximum extent worn out. and easy to disassemble and maintain
Max Payload 30000 kg Double Deck Animal Poultry Livestock Semi Trailer with 3/4 Axles 7

bottom

stronger sturction
Max Payload 30000 kg Double Deck Animal Poultry Livestock Semi Trailer with 3/4 Axles 8

Axle suspension and brake system

BPW Fuwa worldwide best axles worki with WABCO brake valve, More effectively brake for safe and save tire cost , Fix quality springs and suspension , support longer service life, save maintain cost
Max Payload 30000 kg Double Deck Animal Poultry Livestock Semi Trailer with 3/4 Axles 9

Landing Gear

The warranty period of Chinese brand/JOST landing gear is more than 5 years. The gearbox uses low temperature premium chassis oil and is rated for service from -30°C to 120°C
Max Payload 30000 kg Double Deck Animal Poultry Livestock Semi Trailer with 3/4 Axles 10

Leaf Spring

Usually six sets, 10pcs leaf spring , 13mm thickness, 90mm width
Max Payload 30000 kg Double Deck Animal Poultry Livestock Semi Trailer with 3/4 Axles 11

Stronger instruction



Recommend Products
Max Payload 30000 kg Double Deck Animal Poultry Livestock Semi Trailer with 3/4 Axles 12
Max Payload 30000 kg Double Deck Animal Poultry Livestock Semi Trailer with 3/4 Axles 13
Max Payload 30000 kg Double Deck Animal Poultry Livestock Semi Trailer with 3/4 Axles 14
Max Payload 30000 kg Double Deck Animal Poultry Livestock Semi Trailer with 3/4 Axles 15
Max Payload 30000 kg Double Deck Animal Poultry Livestock Semi Trailer with 3/4 Axles 16
Max Payload 30000 kg Double Deck Animal Poultry Livestock Semi Trailer with 3/4 Axles 17
Max Payload 30000 kg Double Deck Animal Poultry Livestock Semi Trailer with 3/4 Axles 18
Max Payload 30000 kg Double Deck Animal Poultry Livestock Semi Trailer with 3/4 Axles 19
Max Payload 30000 kg Double Deck Animal Poultry Livestock Semi Trailer with 3/4 Axles 20
Max Payload 30000 kg Double Deck Animal Poultry Livestock Semi Trailer with 3/4 Axles 21
Max Payload 30000 kg Double Deck Animal Poultry Livestock Semi Trailer with 3/4 Axles 22
Max Payload 30000 kg Double Deck Animal Poultry Livestock Semi Trailer with 3/4 Axles 23
Company Profile
Max Payload 30000 kg Double Deck Animal Poultry Livestock Semi Trailer with 3/4 Axles 24
About us
Shandong Wosheng Special Vehicle Manufacturer Co., LTD.
Our Company mainly produce fence semi trailer, lowbed semi trailer , low fence semi trailer , rear dump semi trailer, container flat semi trailer, fuel oil semi trailer, etc all kinds of semi trailer, Our company have more than 20 years produce and exporting experience Quality is firstly, Credit is our base for business, Welcome to know us and build business relationship.
Max Payload 30000 kg Double Deck Animal Poultry Livestock Semi Trailer with 3/4 Axles 25
Max Payload 30000 kg Double Deck Animal Poultry Livestock Semi Trailer with 3/4 Axles 26
Factory :
Our factory commit to strict quality control and thoughtful customer service, our experienced staff can discuss your requirements at any time to ensure your full satisfaction. We not only want to be perfect in
appearance, but also pursue the delicacy of detail. We have advanced modern equipment, strong technical force to ensure customer satisfaction of products and timely delivery.
Max Payload 30000 kg Double Deck Animal Poultry Livestock Semi Trailer with 3/4 Axles 27
Packing and Loading
Max Payload 30000 kg Double Deck Animal Poultry Livestock Semi Trailer with 3/4 Axles 28
Container usually us 45 feet
Usually by bulk
Certification
Max Payload 30000 kg Double Deck Animal Poultry Livestock Semi Trailer with 3/4 Axles 29

we have obtained the World material Manufacturing Factory Certificate, 3C Certificate and ISO9000 Quality Management Certification. We are also a national high-tech enterprise and have obtained more than 30 invention patents and utility model patents.
Max Payload 30000 kg Double Deck Animal Poultry Livestock Semi Trailer with 3/4 Axles 30
Max Payload 30000 kg Double Deck Animal Poultry Livestock Semi Trailer with 3/4 Axles 31
We are your most reliable cooperation partner
We are a national high-tech enterprise and have obtained more than 30 invention patents and utility model patents. We have attracted customers from all over the world, whether choosing the current product from our catalog or seeking technical support for your application, you can talk to our customer service colleagues about your procurement needs.
High quality , factory lower price , good service !
Max Payload 30000 kg Double Deck Animal Poultry Livestock Semi Trailer with 3/4 Axles 32
FAQ

Q1. Are you a factory or trade company ? We are a comprehensive industrial and trade enterprise integrating product design, scientific research and development, production and sales. Welcome to visit our factory at any time.

Q2. Could you accept special design and specification? Sure of course. As we all know that the traffic regulations are different in different areas, our professional engineers will design and our well-trained staff will produce according to customer special requirements. Such as: special Size, special control, or OEM/ODM etc.

Q3. Are you looking for an agent? Yes, we're looking for the agent all over the world, you are welcome to contact us for further discussion.

Q4. How to control quality? We set up all process inspection and quality control standard, include raw materials, production process, finished products. Advanced equipment and standard inspection process ensure the quality.

Q5. what services can we provide? Accepted Delivery Terms: EXW, FOB, CFR, CIF
