Product Details:
|
| Use: | Truck Trailer | Type: | Semi-Trailer |
|---|---|---|---|
| Material: | Steel | Size: | 12500x2500x1600-3100mm Or Customizable |
| Max Payload: | >30000 Kg | Function: | Transport 20ft 40ft Container |
| Main Beam: | Q345B, Height 0.5m, Upper /down/middle Plate Is 14/16/8mm | Color: | Customized Color |
| Leaf Spring: | 90(w)mm*13/16(thickness)mm*10(layer) | King Pin: | 2"(50mm)or3.5"(90mm) |
| Axle: | 13ton*3 Axles | Suspension: | Mechanical Suspension |
| Landing Gear: | 28t Heavy Duty Landing Gear | Tire: | 12.00R22.5 |
| Tools Box: | 1 Standard |
|
Flatbed Semi Trailer Specification
|
|
|
||
|
20FT FLATBED SEMI TRAILER
|
40FT FLATBED SEMI TRAILER
|
45FT FLATBED SEMI TRAILER
|
||
|
Brand: Wosheng
|
Brand: Wosheng
|
Brand: Wosheng
|
||
|
2 Axles/3 Axles
|
2 Axles/3 Axles
|
3 Axles/4 Axles
|
||
|
20ft container or cargo loading
|
1*40ft/2*20ft Container or cargo loading
|
1*40ft/1*45ft container or cargo loading
|
||
|
Loading Capacity: 20 - 60 Tons
|
Loading Capacity: 30 - 80 Tons
|
Loading Capacity: 30 - 100 Tons
|
||
|
Gooseneck Type: Yes
|
Gooseneck Type: Yes
|
Gooseneck Type: Yes
|
||
|
Tandem Type: Yes
|
Tandem Type: Yes
|
Tandem Type: Yes
|
||
|
Main Beam
|
|
|
||
|
Material: Q345/T700
|
Material: Q345/T700
|
Material: Q345/T700
|
||
|
Upper Plate Thickness: 12mm
|
Upper Plate Thickness: 16mm
|
Upper Plate Thickness: 16mm
|
||
|
Middle Plate Thickness: 6mm
|
Middle Plate Thickness: 10mm
|
Middle Plate Thickness: 10mm
|
||
|
Lower Plate Thickness: 14mm
|
Lower Plate Thickness: 18mm
|
Lower Plate Thickness: 18mm
|
||
|
Height: 500mm
|
Height: 500mm
|
Height: 500mm
|
||
|
Platform Thickness: 2.5mm
|
Platform Thickness: 3mm
|
Platform Thickness: 3mm
|
||
|
Product Dimension
|
|
|
||
|
L 7000mm*W 2500mm*H 1570mm
|
L 12400mm*W 2500mm*H 1570mm
|
L 13950mm*W 2500mm*H 1600mm
|
||
|
Axles
|
|
|
||
|
2/3 Axles *13/16 Ton
WOSHENG/FUWA/BPW/Othe |
2/3 Axles *13/16 Ton
WOSHENG/FUWA/BPW/Other |
3/4 Axles *13/16 Ton
WOSHENG/FUWA/BPW/Other |
||
|
Tire
|
|
|
||
|
12R22.5 (8/12 Pieces)
Linglong/Triangle/Double-Coin/Bridgestone/ Other Brand |
12R22.5 (8/12 Pieces)
Linglong/Triangle/Double-Coin/Bridgestone/ Other Brand |
12R22.5 (8/12 Pieces)
Linglong/Triangle/Double-Coin/Bridgestone/ Other Brand |
||
|
Rim
|
|
|
||
|
9.00*22.5 (8/12 Pieces) Steel/Aluminum
|
9.00*22.5 (8/12 Pieces) Steel/Aluminum
|
9.00*22.5 (8/12 Pieces) Steel/Aluminum
|
||
|
Leaf Spring
|
|
|
||
|
90mm*13mm*10/90mm*16mm*10Pcs
|
90mm*13mm*10/90mm*16mm*10Pcs
|
90mm*13mm*10/90mm*16mm*10Pcs
|
||
|
King Pin
|
|
|
||
|
50#(2")/90#(3.5") JOST/Other Brand
|
50#(2")/90#(3.5") JOST/Other Brand
|
50#(2")/90#(3.5") JOST/Other Brand
|
||
|
Landing Gear
|
|
|
||
|
28 Ton Two Speed,JOST/Other Brand
|
28 Ton Two Speed,JOST/Other Brand
|
28 Ton Two Speed,JOST/Other Brand
|
||
|
Twist Lock
|
|
|
||
|
4 Sets
|
12 Sets
|
12 Sets
|
||
|
Vehicle Painting
|
|
|
||
|
Electrophoresis painting
|
Electrophoresis painting
|
Electrophoresis painting
|
||
