12.4m Length 50T 3 Axle Side Plate Side Fence Semi Trailer with Mechanical Suspension

12.4m Length 50T 3 Axle Side Plate Side Fence Semi Trailer with Mechanical Suspension
12.4m Length 50T 3 Axle Side Plate Side Fence Semi Trailer with Mechanical Suspension 12.4m Length 50T 3 Axle Side Plate Side Fence Semi Trailer with Mechanical Suspension 12.4m Length 50T 3 Axle Side Plate Side Fence Semi Trailer with Mechanical Suspension 12.4m Length 50T 3 Axle Side Plate Side Fence Semi Trailer with Mechanical Suspension 12.4m Length 50T 3 Axle Side Plate Side Fence Semi Trailer with Mechanical Suspension 12.4m Length 50T 3 Axle Side Plate Side Fence Semi Trailer with Mechanical Suspension

Large Image :  12.4m Length 50T 3 Axle Side Plate Side Fence Semi Trailer with Mechanical Suspension

Product Details:
Place of Origin: Shandong, China
Brand Name: Yun Cheng
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: $9,000.00/sets 1-4 sets
Payment Terms: T/T, L/C
Contact Now

12.4m Length 50T 3 Axle Side Plate Side Fence Semi Trailer with Mechanical Suspension

Description
Use: Truck Trailer Type: Semi-Trailer
Material: Steel Size: 12400x2500x3650mm
Max Payload: 80tons Color: Customization
Axle: 3/4 Axles King Pin: 2"(50#) Or 3/5"(90#)
Main Bean: Q345B Rim: 9.00-22.5
Tire: 12.00R 22.5 Suspension: Mechanical Suspension Or Air Suspension
Brake System: Air Champer Lead Time: 15 Days
Condition: New

Products Description
12.4m Length 50T 3 Axle Side Plate Side Fence Semi Trailer with Mechanical Suspension 0

1. Capable of rough road condition International standard heavy duty chassis and running system applied to cope with rough road condition.
12.4m Length 50T 3 Axle Side Plate Side Fence Semi Trailer with Mechanical Suspension 1
2. Steel structure High tensile steel material with tensile and high load capacity and advanced design to achieve lower weight with high carrying capacity, reduce operation cost.
12.4m Length 50T 3 Axle Side Plate Side Fence Semi Trailer with Mechanical Suspension 2

3.Automatic welding Submerged arc Automatic welding construction, Keypoint reinforces and purposeful welding avoid some parts easier lose welding according to experience support vehicle longer time working without repairing.
12.4m Length 50T 3 Axle Side Plate Side Fence Semi Trailer with Mechanical Suspension 3

4.Quality Axles Suspensions and Brake System BPW, FUWA worldwide best axles work with WABCO brake valve, more effectively brake for safe and save tire cost Fix quality springs and suspensions, support longer service life, save maintenance cost.
12.4m Length 50T 3 Axle Side Plate Side Fence Semi Trailer with Mechanical Suspension 4

5.We adopt the world famous brand of parts, like JOST, WABCO braking valve etc. And the main part is Hydraulic support system. It is stable and long service life.
Drawing
12.4m Length 50T 3 Axle Side Plate Side Fence Semi Trailer with Mechanical Suspension 5
Wosheng Fence Cargo Semi Trailer(Customerize and OEM Service Available)
Application
Coal/ Livestock/Vegetable/Cargo Loading
Product Name
2 axles fence semi trailer
3 axles fence semi trailer
4 axles fence semi trailer
Size（mm)
9500/11000*2500*2800/3800
12500/13000*2500*2800/3800
12500/13000*2500*2800/3800
Payload
30-60Tons
30-80Tons
40-100Tons
Main beam
Height: 500mm,                          Upper plate is 12mm,
Middle plate is 6mm,
Down plate is 14mm ,
Material is Q345B Steel.
Height: 500mm,                          Upper plate is 16mm,                  Middle plate is 10mm,                Down plate is 18mm ,
Material is Q345B Steel.
Height: 500mm,                          Upper plate is 18mm,                      Middle plate is 12mm,                    Down plate is 20mm,                  Material is Q345B Steel.
Axles
2*13T/16Ton
Wosheng/ FUWA/BPW/Other
3*13T/16Ton
Wosheng/FUWA/BPW/Other
4*13T/16Ton
Wosheng/ FUWA/BPW/Other
Side Wall Height
600mm-1700mm (can be customized)
Side beam
16mm channel steel (Material is Q235B steel)
Bottom Platform
3mm checquered steel plate
Suspension
Mechanical suspension (Air suspension optional)
Leaf spring
90(width)mm*13(thickness)mm*10 layer(especial for exporting market)
Tire
12R22.5 / 11.00R20 8/12pcs (Other size optional)
Rim
9.00-22.5 / 11.00R20 8/12pcs (Other size optional)
Kin pin
Jost brand 2.0 or 3.5 inch
Landing gear
Jost brand 28Ton two speed
Braking system
Wabco re 6 relay valve; T30/30+T30 spring brake chamber; two units of 45L air tanks
Electrical
LED light , 7 ways ,24V
Tool box
One piece 1m *0.5m*0.5m ( size can be customized)
Twist locks
Optional
ABS
Optional
Painting
1.Sand blasting processing clean rust.2.Coat of anticorrosive primer.
3.Coats of finish urethane paint.
4.Color as customer choice.
Shipping terms
By bulk vessel, RORO, or 40HQ container
Specification
12.4m Length 50T 3 Axle Side Plate Side Fence Semi Trailer with Mechanical Suspension 6
Rational Analysis design:

The checker plate of the flat part can effectively prevent the loose sliding of the goods.
Twist Lock:
Customers can also change the number of locks according to their needs Customers can change the number of locks according to your own needs.
12.4m Length 50T 3 Axle Side Plate Side Fence Semi Trailer with Mechanical Suspension 7
12.4m Length 50T 3 Axle Side Plate Side Fence Semi Trailer with Mechanical Suspension 8
Anti-Tire abrasion Suspension:

Specially designed anti-Tire abrasion suspension system. Prevent tire offset after loading, maximally avoid tire
abrasion.Meanwhile,Easy to disassemble and maintain.
Brake System:
T30/30 Spring brake chamber. WABCO valve,ABS/EBS system optional. dual line brake pipe.
12.4m Length 50T 3 Axle Side Plate Side Fence Semi Trailer with Mechanical Suspension 9
12.4m Length 50T 3 Axle Side Plate Side Fence Semi Trailer with Mechanical Suspension 10
Landing Gear
The warranty period of Chinese brand/JOST landing gear is more than 5 years. The gearbox uses low temperature premium chassis oil and is rated for service from -30°C to 120°C.
12.4m Length 50T 3 Axle Side Plate Side Fence Semi Trailer with Mechanical Suspension 11

Title goes here.

Side wall :
The Height is 400-1200mm for your choose
Weld by automatic corrugated plate welding robot, the quality is good, the welded seam is beautiful, the side wall strong and durable
12.4m Length 50T 3 Axle Side Plate Side Fence Semi Trailer with Mechanical Suspension 12

Diamond plateform(Non-Slip)

3mm/4mm/5mm for your chioce , it depends on the loading capacity of trailer
12.4m Length 50T 3 Axle Side Plate Side Fence Semi Trailer with Mechanical Suspension 13

Painting

Electrophoretic primer and power spray, the paint sureface is clean and smooth , ensuring that each part has paint, and no rust water will be produced in the later stage
12.4m Length 50T 3 Axle Side Plate Side Fence Semi Trailer with Mechanical Suspension 14
12.4m Length 50T 3 Axle Side Plate Side Fence Semi Trailer with Mechanical Suspension 15
12.4m Length 50T 3 Axle Side Plate Side Fence Semi Trailer with Mechanical Suspension 16
This series of semi-trailers are designed with cross-beam structure in the main frame, and for the longitudinal beam, it’s
designed as flat bed or goose-neck. The height of the middle plate (manganese plate) is from 400mm to 550mm. The longitudinal beam is welded by automatic submerged welding. The frame is shot blasted. The beam penetrates the longitudinal beam and is welded as a whole.
12.4m Length 50T 3 Axle Side Plate Side Fence Semi Trailer with Mechanical Suspension 17
12.4m Length 50T 3 Axle Side Plate Side Fence Semi Trailer with Mechanical Suspension 18
12.4m Length 50T 3 Axle Side Plate Side Fence Semi Trailer with Mechanical Suspension 19
Recommend Products
12.4m Length 50T 3 Axle Side Plate Side Fence Semi Trailer with Mechanical Suspension 20
12.4m Length 50T 3 Axle Side Plate Side Fence Semi Trailer with Mechanical Suspension 21
12.4m Length 50T 3 Axle Side Plate Side Fence Semi Trailer with Mechanical Suspension 22
12.4m Length 50T 3 Axle Side Plate Side Fence Semi Trailer with Mechanical Suspension 23
12.4m Length 50T 3 Axle Side Plate Side Fence Semi Trailer with Mechanical Suspension 24
12.4m Length 50T 3 Axle Side Plate Side Fence Semi Trailer with Mechanical Suspension 25
12.4m Length 50T 3 Axle Side Plate Side Fence Semi Trailer with Mechanical Suspension 26
12.4m Length 50T 3 Axle Side Plate Side Fence Semi Trailer with Mechanical Suspension 27
12.4m Length 50T 3 Axle Side Plate Side Fence Semi Trailer with Mechanical Suspension 28
12.4m Length 50T 3 Axle Side Plate Side Fence Semi Trailer with Mechanical Suspension 29
12.4m Length 50T 3 Axle Side Plate Side Fence Semi Trailer with Mechanical Suspension 30
12.4m Length 50T 3 Axle Side Plate Side Fence Semi Trailer with Mechanical Suspension 31
Company Profile
12.4m Length 50T 3 Axle Side Plate Side Fence Semi Trailer with Mechanical Suspension 32
About us
Shandong Wosheng Special Vehicle Manufacturer Co., LTD.
Our Company mainly produce fence semi trailer, lowbed semi trailer , low fence semi trailer , rear dump semi trailer, container flat semi trailer, fuel oil semi trailer, etc all kinds of semi trailer, Our company have more than 20 years produce and exporting experience Quality is firstly, Credit is our base for business, Welcome to know us and build business relationship.
12.4m Length 50T 3 Axle Side Plate Side Fence Semi Trailer with Mechanical Suspension 33
Factory :
Our factory commit to strict quality control and thoughtful customer service, our experienced staff can discuss your requirements at any time to ensure your full satisfaction. We not only want to be perfect in
appearance, but also pursue the delicacy of detail. We have advanced modern equipment, strong technical force to ensure customer satisfaction of products and timely delivery.
12.4m Length 50T 3 Axle Side Plate Side Fence Semi Trailer with Mechanical Suspension 34
12.4m Length 50T 3 Axle Side Plate Side Fence Semi Trailer with Mechanical Suspension 35
12.4m Length 50T 3 Axle Side Plate Side Fence Semi Trailer with Mechanical Suspension 36
Packing and Loading
12.4m Length 50T 3 Axle Side Plate Side Fence Semi Trailer with Mechanical Suspension 37
Container usually us 45 feet
Usually by bulk
Certification
12.4m Length 50T 3 Axle Side Plate Side Fence Semi Trailer with Mechanical Suspension 38

we have obtained the World material Manufacturing Factory Certificate, 3C Certificate and ISO9000 Quality Management Certification. We are also a national high-tech enterprise and have obtained more than 30 invention patents and utility model patents.
12.4m Length 50T 3 Axle Side Plate Side Fence Semi Trailer with Mechanical Suspension 39
12.4m Length 50T 3 Axle Side Plate Side Fence Semi Trailer with Mechanical Suspension 40
We are your most reliable cooperation partner
We are a national high-tech enterprise and have obtained more than 30 invention patents and utility model patents. We have attracted customers from all over the world, whether choosing the current product from our catalog or seeking technical support for your application, you can talk to our customer service colleagues about your procurement needs.
High quality , factory lower price , good service !
12.4m Length 50T 3 Axle Side Plate Side Fence Semi Trailer with Mechanical Suspension 41
FAQ

Q1. Are you a factory or trade company ? We are a comprehensive industrial and trade enterprise integrating product design, scientific research and development, production and sales. Welcome to visit our factory at any time.

Q2. Could you accept special design and specification? Sure of course. As we all know that the traffic regulations are different in different areas, our professional engineers will design and our well-trained staff will produce according to customer special requirements. Such as: special Size, special control, or OEM/ODM etc.

Q3. Are you looking for an agent? Yes, we're looking for the agent all over the world, you are welcome to contact us for further discussion.

Q4. How to control quality? We set up all process inspection and quality control standard, include raw materials, production process, finished products. Advanced equipment and standard inspection process ensure the quality.

Q5. what services can we provide? Accepted Delivery Terms: EXW, FOB, CFR, CIF
